8*4 Four Axles T-Lift Machine shop Truck Series
New product
EQ3310AT13 Four Axles T-Lift Machine shop Truck
1 Item
In stock
Warning: Last items in stock!
Data sheet
| Compositions | Non-asbestos: NA |
| Styles | Overhaul package: FS |
| package | Bare packing |
More info
1. Utilize superior quality and limited Dongfeng dump truck chassis, with advanced technology, reliable performance.
2. Adopting late-model high strength steel, which can realize weight reduction, decrease use-cost of vehicle, improves vehicle service life.
3. Semi-automatic flow process equipments guarantee product excellent quality.
4. This series of dump trucks with sync put hydraulic lifting structure, select and use leading domestic high-quality and premium brands hydraulic components. Auxiliary frame apply rectangular steel tube structure, and for the chassis base we use rectangular tube four longitudinal beam structures.
5. Wide tail multi-key torsion structure can ensure the stability of lifting.
6. Applicable to transport urban waste, coal, sand, stone, etc. goods in short& medium -distance
|
EQ3310AT13 Four Axles T-Lift Machine shop Truck |
|
|
Vehicle Model |
EQ3300AT13 Dump Truck |
|
Overall Dimensions(mm) |
10590,10790,10900*2500*3450 |
|
Cargo Body Inner Size(mm) |
8000,8200,8500*2260*1000,970，1000 |
|
Wheelbase(mm) |
1950+4250+1350 |
|
Gross Weight(kg) |
64620 |
|
Rated Loaded Weight(kg) |
50000 |
|
Curb Weight(kg) |
14620 |
|
Engine Model |
L340 30 |
|
Displacement/Power |
8900/250 |
|
Displacement standar |
Euro 3 |
|
Oil Consumption(L/100km) |
21.1 |
|
Maximum speed (km/h) |
80 |
|
Cab Type |
Flat head and single row with a sleeper can be flipped |
|
Audio Configuration |
Mp4 |
|
Heating and Cooling System |
Air Conditioning, warm air |
|
Cold Boot Temperature Range |
General condition:-10to55℃；special circumstances：-40to55 |
|
Transmission |
Shanxi Fast 9 Gear transmission; Dongfeng 9Gear transmission |
|
Oil tank capacity |
Completed steel 350L |
|
Tire Size |
11.00-20, 11.00R20, 12.00-20, 12.00R20 |
|
Lifting Type |
Rear or side dump truck |
|
Chassis Model |
DFL3310A13 |
